CSL-SO系列

谐波减速器技术参数与性能曲线详解：杯型与空心型产品家族及产品代码解析

产品介绍

谐波减速器
机械参数
重量：1420g±20g
极数：42极
相数：3相
驱动方式：FOC磁场定向控制
减速比：10:1

详细说明

技术参数

Featuring a cup-shaped enclosed cylinder flexspline, the input shaft mates with the inner bore of the wave generator via a flat key connection.

With the circular spline fixed, output is transmitted through the flexspline end.

性能曲线

Harmonic Reducers Overview
Our harmonic reducers are broadly categorized into two main product families based on flexspline geometry: Cup-Type Reducers and Hollow-Type Reducers. Each family encompasses multiple models with various reduction ratios.
Product Code Example
HSL-20-50-UH-C
①②③-④-⑤-⑥-⑦
Code Breakdown:
Flexspline Type
H: Hollow-Type
C: Cup-Type
Torque Class
S: Standard Torque
D: Enhanced Torque
Length Design
L: Standard Length
M: Shorter Barrel
Model Specification
Corresponding to harmonic gear pitch circle diameter
Available sizes: 14 | 17 | 20 | 25 | 32
Reduction Ratio
Options: 30 | 50 | 80 | 100 | 120 | 160
Input Connection Type
SO: Standard disc cam wave generator with input shaft mating via flat key
SC: Cross-slider coupling wave generator
UH: Hollow standard cylinder structure
SH: Hollow simplified cylinder structure
UJ: Hollow cylinder structure with shaft input
Product Configuration
C: Component (unmarked indicates fully assembled unit)
